SHAFT SUPPORT BLOCK WBA-16C-FO
Manufacturer: Bosch Rexroth
Material #: R105801600
Model : SHAFT SUPPORT BLOC WBA-16C-FO
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT BLOC WBA-16C-FO (R105801600) is a high-quality shaft support block designed to provide secure and precise mounting for linear motion applications. This compact, aluminum support block is engineered to accommodate a shaft diameter of 'd,' although the exact measurement is not specified. The WBA-16C-FO model features topside clamping which offers better accessibility and enhances security by incorporating a clamping screw with a larger thread diameter, ensuring a firm grip on the supported shaft.
The product's design includes drill holes for fastening from both above and below, facilitating easy installation and quick alignment. It boasts a precise design with a reference edge, allowing for more accurate positioning within your assembly. This feature is particularly beneficial for applications requiring high levels of precision and repeatability.
Additionally, the SHAFT SUPPORT BLOC WBA-16C-FO's low-profile format makes it ideal for fitting linear sets with compact linear bushings, where space constraints are an issue. Its aluminum construction not only provides robustness but also keeps the weight minimal without compromising on strength or durability.
This product is part of Bosch Rexroth's range of accessories for linear bushings and is categorized under their Productgroup ID. It offers an economical alternative to in-house designs, saving time and resources in the process of engineering support structures for linear guides. The tightening torque sizes N and H as well as other size specifications such as E, SW, and H are meticulously calibrated to meet stringent quality standards, ensuring reliable performance in various industrial applications.
$39.30 USD
More are expected on June 9, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as June 9, 2025 when ordered in
