SHAFT SUPPORT BLOCK WBG-30F

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT BLOC WBG-30F (R105603000) is a robust component designed for supporting and aligning shafts in linear motion applications. This shaft support block is made from high-quality lamellar graphite cast iron, which ensures durability and a long service life. It is specifically engineered to facilitate the alignment of shafts and prevent overloading of linear bushings due to non-parallel shafts, which can be a common issue when installing shafts in custom-made bores. Featuring a side clamping screw, the WBG-30F allows for easy installation and quick alignment, streamlining the assembly process. The precision design includes a reference edge that aids in achieving accurate positioning during installation. This feature makes it more cost-effective than creating custom in-house designs since it reduces both time and material costs associated with such endeavors. The flange material of this support block is gray cast iron, which provides a stable base for the supported shaft and enhances the overall rigidity of the assembly. The product belongs to Bosch Rexroth's product group ID and comes with various size specifications such as Size V, Size E, Size SW, and Size L to accommodate different requirements. Intended for use with linear bushings and shafts, this support block represents an essential accessory that contributes to the proper functioning of linear guide systems. Its housing material is also cast iron, contributing to its overall weight and ensuring that it remains firmly anchored in place during operation. Overall, the Bosch Rexroth SHAFT SUPPORT BLOC WBG-30F (R105603000) is an indispensable component for those seeking a reliable solution for mounting and aligning linear motion systems efficiently and effectively.
