SHAFT SUPPORT RAIL WU50-AF2-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU50-AF2-600 (R105075000) is a high-quality component designed for creating precise and rigid linear guides. This shaft support rail is tailored to work with open linear bushings, making it an ideal choice for long guides or high-load applications where self-supporting shafts are not viable due to potential shaft warping. The product features an aluminum construction with a flange and bore spacing type, ensuring durability and stability. This model is engineered to provide extra rigidity through the careful adaptation of the support rail to the linear bushing size, achieving the optimal pressure angle for fitting the shaft. The use of large fastening bolts further enhances this rigidity. The WU50-AF2-600 is versatile, allowing for unlimited length when using interconnecting shafts, and it offers additional degrees of freedom in the circumferential direction compared to profiled guide rails. Such capabilities make this Bosch Rexroth support rail suitable for applications that require a low-height linear guide system but are prone to warping due to imprecise substructures. It comes in a standard length as per table specifications and can be used in various requirements where robust support and precision are critical. The product group ID, size specifications such as thread diameter (Mx), bore spacing type, length (L), material, and weight are all defined to meet exacting standards that ensure compatibility with precision steel shafts and facilitate integration into a wide range of linear motion systems.
