SHAFT SUPPORT RAIL WU25-AF1-600

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SHAFT SUPPORT RAIL WU25-AF1-600 (R105062500) is a high-quality component designed for creating precise and rigid linear guides. This shaft support rail is made from aluminum, providing a durable and lightweight solution for supporting linear motion applications. It features a flange design with bore spacing that adheres to standard lengths as outlined in the accompanying table. The R105062500 is engineered to offer extra rigidity, ensuring stability and precision in linear motion systems. The careful adaptation of the support rail to the size of the linear bushing allows for an optimal pressure angle when fitting the shaft, which is further reinforced by large fastening bolts. This design choice makes it suitable for use with open linear bushings and ideal for long guides or high-load applications where self-supporting shafts are not feasible due to potential shaft warping. Additionally, this product allows for unlimited length configurations when using interconnecting shafts, making it versatile for various application requirements. The support rails provide additional degrees of freedom in the circumferential direction compared to profiled guide rails, making them an excellent choice for scenarios where other linear guides may be prone to warping due to imprecise substructures. The Bosch Rexroth SHAFT SUPPORT RAIL WU25-AF1-600 supports various sizes and specifications including thread diameter Mx, size V, size t, size A, product group ID, thread x lead Mx, size H angle, size E bore spacing type, length L material shaft support rails made of Aluminum with a specified shaft diameter d. It's part of a larger product group that includes precision steel shafts with shaft support rails designed to work seamlessly with linear bushings and shafts. The weight and tolerance specifications ensure compatibility and ease of integration into existing systems requiring high levels of accuracy and rigidity.
