LINEAR-SET LSA-B-30-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSA-B-30-DD (R103583020) is a high-quality linear set crafted from aluminum, featuring a lightweight precision housing with a super linear bushing B, designed without a self-alignment feature. This model includes external seals and offers relubrication capabilities, ensuring long-term performance and reduced maintenance. The set is equipped with two integrated wiper seals on either side, providing protection against contaminants and preserving the integrity of the system. With a standard version shaft diameter of 30 mm, this linear set is engineered to deliver smooth motion in linear applications. The frictional drags are minimal when not under radial load, but they vary depending on speed and lubrication conditions. The dynamic load capacity C indicates the robustness of the set under the main loading direction; for other directions, specific factors need to be applied to determine accurate load capacities. The LINEAR-SET LSA-B-30-DD can handle maximum accelerations and is rated for use within an ambient temperature range of -20°C to 80°C. It boasts an impressive static load rating and breakaway force that ensure reliability even under high-stress conditions. For rapid movements, it can achieve speeds up to 5 m/s; however, at such speeds, service life may be reduced due to increased wear on plastic components. This product has been tested extensively for durability, demonstrating travel distances ranging from 100 km to 1000 km without failure. Its design caters to precision guides that require straightforward installation processes with a fixed working bore diameter. Weighing in at just 0.4 kg, the Bosch Rexroth LINEAR-SET LSA-B-30-DD is ideal for applications where precision and lightness are paramount. It provides an efficient solution for guiding mechanisms across various fields where reliable linear motion is essential.
