TOLERANCE RING BN45X23

Name: TOLERANCE RING BN45X23
Price: 2.72 USD
Availability: InStock

Manufacturer: Bosch Rexroth

Material #: R082004503

Model : TOLERANCE RING BN45X23

$2.72 USD

Availability: 11 In Stock

Add to Cart

Available for immediate shipment

Qty: 1 Delivered as early as March 14, 2025 when ordered in 23 hours and 32 minutes.

TOLERANCE RING BN45X23

Tolerance ring (BN), size = 45 X 23, carbon steel

Tolerance ring
Type BN: The circumferential flat edges lie on the inner diameter of the tolerance ring. For use with a unit bore system.
Tolerance ring diameter (d) = 45
Tolerance ring width (b) = 23
Carbon steel

Unpacked Weight: 0.0103 kg

Quick, economic installation
Compensates the differences in thermal expansion between machine elements made of different materials
Eliminates the need for keyways or other positive-locking connections
Connecting parts have a simple design
High temperature stability
Special sizes available on request
Extremely low-cost machine element
Resistant to various types of chemical stress
Fixed and secure connection of machine parts
Large tolerance zone with connecting parts

Data Sheet

Download Data Sheet

Productgroup ID	17
Size b	23
Material footnote	Up to 200°C continuous operation, brief peaks up to 250°C
Size d	45
Transferable torque footnote 1	Observe the general technical notes and information.
Transferable torque footnote 2	In case of free installation with 20% reduction, see section “Calculations” for the guideline values
Permissible radial load footnote 2	Considerably smaller values are permitted for pulsating and alternating loads. Please consult us.
Weight	0.0103
Transferable torque	170
Permissible radial load	17000
Nominal size	45 x 23

TOLERANCE RING BN45X23

Manufacturer: Bosch Rexroth

Material #: R082004503

Model : TOLERANCE RING BN45X23

Availability: 11 In Stock
