TOLERANCE RING AN210X33

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING (R081021001) is a precision-engineered component designed to provide a fixed and secure connection between machine parts. This tolerance ring, identified by the model code AN210X33, is crafted from carbon steel, ensuring high temperature stability and resistance to various types of chemical stress. It is particularly useful for compensating differences in thermal expansion between connected elements made of different materials. With dimensions specified for a nominal size of 210 mm in diameter (d) and a width (b), this tolerance ring features circumferential flat edges on its outer diameter, making it suitable for use with a standard nominal shaft. Its design eliminates the need for keyways or other positive-locking connections, streamlining the assembly process and reducing manufacturing complexity. The TOLERANCE RING AN210X33 boasts quick and economical installation while providing an extremely low-cost solution as a machine element. It has been engineered to offer a large tolerance zone when connecting parts, ensuring reliability even when faced with considerable variations or irregularities in component sizing. This model offers excellent performance under continuous operation up to a certain temperature and can handle brief peak temperatures beyond that threshold. The product's specifications also include guidelines for transferable torque and permissible radial load, which highlight its capability to maintain integrity under mechanical stress. Special sizes are available upon request to accommodate unique application requirements. Overall, the Bosch Rexroth TOLERANCE RING AN210X33 provides an efficient solution for creating stable connections in machinery without the added cost or complexity of traditional joining methods. Its robust design ensures long-term reliability in diverse operating conditions, making it an invaluable component in various mechanical assemblies.
