TOLERANCE RING AN110X19

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING (R081011002) is a precision-engineered component designed to facilitate secure and reliable connections between machine parts. This tolerance ring, identified by the model code AN110X19, is constructed from carbon steel, ensuring high temperature stability and resistance to various types of chemical stress. With its circumferential flat edges located on the outer diameter, the AN110X19 is specifically crafted for use with a standard nominal shaft. The design of this tolerance ring allows for quick and economical installation while compensating for differences in thermal expansion between connected elements made of disparate materials. The absence of keyways or other positive-locking connections simplifies the overall design of the connecting parts, streamlining assembly processes. The AN110X19 boasts an extremely low-cost profile as a machine element without compromising on performance. This model has a large tolerance zone which provides flexibility when dealing with connecting parts, ensuring a fixed and secure fit even under varying conditions. Its specifications include a nominal size of 110x19 mm, which indicates its compatibility with corresponding shaft sizes. The product group ID and material footnote indicate that this tolerance ring can operate continuously up to certain temperatures, with brief peaks at higher temperatures. In terms of mechanical capabilities, the AN110X19 can transfer significant torque values while also supporting permissible radial loads. However, for pulsating and alternating loads, smaller values are recommended; consulting with Bosch Rexroth for specific applications is advised. Special sizes of the TOLERANCE RING can be requested to suit unique requirements or applications where standard sizes may not be adequate. Overall, the Bosch Rexroth TOLERANCE RING AN110X19 is an essential component for creating durable and efficient mechanical connections in various applications.
