TOLERANCE RING AN70X25

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING AN70X25 (R081007002) is a specialized component designed for creating secure, fixed connections between machine parts without the need for keyways or other positive-locking connections. This tolerance ring, featuring circumferential flat edges on its outer diameter, is intended for use with a standard nominal shaft and offers a large tolerance zone, ensuring a simple yet effective design for the connecting parts. Crafted from carbon steel, the AN70X25 model provides high temperature stability and can withstand continuous operation temperatures up to certain degrees Celsius, with brief peaks at higher temperatures. Its material properties also make it resistant to various types of chemical stress. The ring compensates for differences in thermal expansion between different materials, which is crucial in maintaining the integrity of machine elements under varying thermal conditions. The installation process of this tolerance ring is quick and economical, significantly reducing assembly time and costs. It boasts an extremely low-cost profile as a machine element while ensuring a reliable performance. The AN70X25 model has specific dimensions for its diameter (d) and width (b), with the capability to transfer notable torque values. Its design allows it to handle permissible radial loads effectively; however, it's important to note that smaller values are recommended for pulsating and alternating loads. This Bosch Rexroth tolerance ring is suitable for applications where a fixed and secure connection is essential. Special sizes can be requested to meet unique requirements, making it a versatile solution across various applications. The product's weight and detailed technical specifications regarding torque transfer and radial load capacities are provided to ensure proper selection and use within mechanical assemblies.
