TOLERANCE RING AN42X12

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING AN42X12 (R081004201) is a precision-engineered component designed to facilitate the connection of machine elements while compensating for thermal expansion differences between materials. This tolerance ring, characterized by its circumferential flat edges on the outer diameter, is tailored for use with a standard nominal shaft, ensuring compatibility and ease of integration into various applications. Constructed from carbon steel, the AN42X12 offers high temperature stability and durability. Its design simplifies the assembly process by eliminating the need for keyways or other positive-locking connections, which can often complicate installation and maintenance procedures. The tolerance ring's straightforward design not only accelerates assembly but also contributes to economic efficiency. The Bosch Rexroth tolerance ring is suitable for scenarios where there are discrepancies in thermal expansion rates between connected parts. Its ability to absorb such differences makes it an essential component in ensuring the longevity and reliability of machinery. The product's specifications include a defined tolerance ring diameter (d) and width (b), which are critical dimensions that ensure a proper fit and optimal performance. Overall, the AN42X12 tolerance ring is an exemplary solution for creating secure, yet flexible joints within mechanical systems. It stands out due to its robust material choice, thoughtful design that simplifies installation processes, and its capability to maintain integrity under varying thermal conditions.
