TOLERANCE RING AN25X20

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING AN25X20 (R081002503) is a robust machine element designed for creating secure connections between components with simplicity and efficiency. This tolerance ring, featuring a size of 25mm in diameter (d) and a width (b) of 20mm, is constructed from carbon steel, ensuring high temperature stability for continuous operation up to a certain temperature with brief peaks allowable beyond that. Its design incorporates circumferential flat edges on the outer diameter, making it ideal for use with standard nominal shafts. The AN25X20 tolerance ring facilitates quick and economic installations while compensating for differences in thermal expansion between connected machine elements made of dissimilar materials. This feature eliminates the need for keyways or other positive-locking connections, streamlining the design of connecting parts. The product boasts an extremely low-cost profile while offering resistance to various types of chemical stress. Its fixed and secure connection capability supports a large tolerance zone, which can be particularly beneficial when accommodating connecting parts that have simple designs. The Bosch Rexroth tolerance ring ensures transferable torque and permissible radial load within specified limits, with considerably smaller values permitted for pulsating and alternating loads. For applications requiring special sizes or unique specifications, customizations are available upon request. The AN25X20 tolerance ring is an elegant solution for achieving stable connections in machinery without complicating the assembly process or increasing costs unnecessarily. It stands out as an economical choice that does not compromise on performance or reliability.
