TOLERANCE RING ANS225X31

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TOLERANCE RING ANS225X31 (R080422501) is a precision-engineered component designed to facilitate the mounting of larger antifriction bearings, particularly in light metal housings. This tolerance ring is characterized by its slanting edge, which aids in installation and ensures a secure fit. Constructed from carbon steel, the ANS225X31 offers high temperature stability and can withstand continuous operation up to a specified temperature, with brief peaks beyond that threshold. The design of the tolerance ring allows for quick and economical installation while compensating for differences in thermal expansion between machine elements made of dissimilar materials. This eliminates the need for keyways or other positive-locking connections, simplifying the design of connecting parts. The ANS225X31 provides a robust connection that is resistant to various types of chemical stress and ensures a large tolerance zone with connecting components. With its nominal size of 225 mm in diameter by 31 mm in width, the ANS225X31 can handle a specified permissible radial load. However, it is important to note that considerably smaller values are allowed for pulsating and alternating loads; consultation with Bosch Rexroth is recommended for such applications. The tolerance ring's weight and specific product group ID are also detailed, indicating its classification within the manufacturer's product range. Additionally, special sizes of the tolerance ring can be requested to suit unique application requirements. The Bosch Rexroth TOLERANCE RING ANS225X31 stands out as an extremely low-cost machine element that provides a fixed and secure connection between machine parts, enhancing overall machine performance and reliability.
