FLANGE LINEAR BUSHING KBMF-16-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth FLANGE LIN.BUSHING KBMF-16-DD (R074051600) is a high-performance linear bushing designed to provide precise linear movement and support in demanding industrial applications. This rugged all-metal design features a steel ball retainer that is well-suited for harsh environments and heavy contamination, making it ideal for use in woodworking, foundries, and cement plants. The KBMF-16-DD has been engineered with many pockets that act as lubricant reservoirs, allowing for extended lubrication intervals or even lubrication for life. These pockets also serve to collect any dirt that may infiltrate the system to prevent jamming. Equipped with integrated wiper seals, this flange linear bushing ensures cleanliness and longevity by protecting internal components from external contaminants. The hardened and ground outer sleeve along with the POM ball retainer provides a durable housing for the rolling bearing steel balls, ensuring smooth motion and reliable performance. The KBMF-16-DD has a shaft diameter of 'd' and comes with two seals for additional protection. It features a maximum dynamic load capacity (Cmax) and minimum dynamic load capacity (Cmin), which are calculated based on a total travel of 100,000 m; these values can be adjusted for travel distances of 50,000 m as indicated in the footnotes provided by Bosch Rexroth. This model boasts an impressive permissible ambient temperature range from 'min ... max' degrees Celsius but requires consideration of load capacity reductions at higher temperatures if unsealed. With specifications like maximum acceleration (amax), outer diameter (D), breakaway force, maximum permissible linear speed (vmax), friction force, minimum static load capacity (Cmin), size L, maximum static load capacity (Cmax), weight, and format F flange style designating its flanged configuration; this linear bushing is tailored to meet the needs of various linear motion systems where reliability and durability are critical.
