SUPER LINEAR BUSHING KBSH-O-20-VD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPER LINEAR BUSH (R073122045) is a high-precision, fully sealed linear bushing engineered to facilitate the movement of heavy loads with exceptional accuracy and rigidity. Designed with hardened steel load-bearing plates featuring meticulously machined ball guide grooves and a steel load-bearing plate back, this Super SH series model ensures maximum precision. It has the capability to compensate for shaft deflection and misalignment, bolstering its performance in dynamic applications. This open linear bushing is equipped with a POM ball retainer and balls crafted from rolling bearing steel, which are held in place by two metal retaining rings. It boasts an impressive dynamic load capacity and is designed to maintain a low friction coefficient, ensuring smooth operation even under varying load conditions. The Bosch Rexroth SUPER LINEAR BUSH can achieve high travel speeds and is capable of handling maximum accelerations with ease. The product's robust design includes an optional integrated double-lipped wiper seal that helps prevent contamination, extending the lifespan of the bushing in challenging environments. The permissible ambient temperature range for this component spans from -30°C to +80°C, allowing it to function optimally across a wide range of operating conditions. With a size designation of E30, it features an outer diameter (D) of 45mm. The static load capacity underscores its strength and durability for stationary applications. The SUPER LINEAR BUSH is also characterized by its radial clearance precision, which contributes to its overall high-performance profile suitable for various linear motion requirements. Productgroup ID: Linear bushings Dynamic load capacity C: High Weight: 0.3kg Radial clearance shaft/bore: Specified as K, M or H grades Linear guide type: Linear bushing and shaft
