TORQUE RESISTANT BUSHING KBDR4-FM-6DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDR4-FM-6DD (R072620600) is a high-precision component designed for self-supporting, torsionally stiff linear guides that require only one shaft. This miniature flanged version of the torque-resistant linear bushing features four ball guide grooves, which are essential for transferring torque effectively. It is suitable for applications requiring precise and smooth linear motion with the capability to resist torsional forces. The outer sleeve of the KBDR4-FM-6DD is hardened and ground, ensuring durability and consistent performance. The POM ball retainer within the bushing maintains the position of the rolling bearing steel balls, which facilitates reliable movement and load distribution. The integrated wiper seals provide protection against contaminants, prolonging the life of the bushing. This model offers a dynamic load capacity C that represents minimal values due to variable loading directions. Its static torsional moment load capacity Mt further underscores its robust design for handling static forces. The KBDR4-FM-6DD can operate within a wide temperature range, from a minimum permissible ambient temperature to a maximum that ensures adaptability in diverse working environments. Additionally, this linear bushing can be relubricated to maintain optimal performance over time. The product's weight reflects its solid construction without compromising efficiency in motion control applications. Matching shaft profiles with machined ball guide grooves are available but need to be specified according to customer requirements. Overall, the Bosch Rexroth TORQUE RESIST.BUSH KBDR4-FM-6DD (R072620600) is engineered for dynamic applications where controlled linear movement and resistance to torsion are paramount, providing an effective solution for sophisticated mechanical systems requiring high precision and durability.
