LINEAR-SET LSFDR2-30-WV-1200

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSFDR2-30-WV-1200 (R072353087) is a high-quality linear motion set designed for precision applications requiring compact, torque-resistant movement. This linear set is composed of a steel flanged sleeve with one ball guide groove for shafts with diameter d and two ball guide grooves for shafts with larger diameters, ensuring versatile compatibility and smooth operation. The shaft included is of standard length as per the provided table, crafted to fit seamlessly with the flanged sleeve. Notably, this model comes without an external seal and has been engineered to offer stability against cocking loads. Its design facilitates easy installation, especially when setting up two Linear Sets in tandem as outlined in the installation section of its documentation. The hardened steel bearing plates are pre-set to zero clearance by the manufacturer to transmit torque efficiently and maintain precise alignment under load. Maintenance is straightforward with the LSFDR2-30-WV-1200's relubrication feature, which extends the lifespan of the assembly under varying operational conditions. It operates within an ambient temperature range of -20°C to +80°C and can withstand a maximum acceleration (amax) while maintaining its integrity and performance. The dynamic load capacity C and static load rating C0 are minimal values due to potential variability in loading directions. Additionally, it has a dynamic torsional moment load capacity Mt that ensures reliable performance during rotational forces. This Linear Set from Bosch Rexroth is part of Productgroup ID 6, denoting its category within their extensive product offerings. Weighing at 1.2 kg/m, it is both lightweight and robust—a testament to Bosch Rexroth's commitment to engineering excellence. With its size V series designation and F format for linear bushings, this model provides an optimal solution for applications demanding precise linear guidance combined with high durability and ease of maintenance.
