LINEAR-SET LSFDR1-12-WV-900

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSFDR1-12-WV-900 (R072321285) is a high-performance linear motion component designed for precision and stability in various applications. This linear set is composed of a steel flanged sleeve and a shaft, ensuring robustness and resistance to torque. It features one ball guide groove for shaft diameters of 12 mm, while sizes above this come with two grooves, enhancing its capability to handle higher loads with increased stability. The product is engineered without an external seal, offering a compact design that can be used in environments where space is at a premium. The absence of a seal also means there are fewer parts that could potentially wear out or require maintenance. However, it remains relubricatable, allowing for easy maintenance and extended service life. With hardened steel bearing plates set to zero clearance from the factory, the LINEAR-SET ensures precise linear motion with minimal play, which is essential for applications requiring high accuracy. Its design also provides excellent stability against cocking loads; this feature becomes particularly beneficial when installing two Linear Sets as recommended in the installation section. This model has been tested to function reliably within a temperature range of -20°C to +80°C, making it suitable for use in various working environments. It can withstand maximum accelerations (amax) and achieve high linear speeds (vmax), ensuring efficient operation under dynamic conditions. The dynamic load capacity (C) and static load capacity (C0) are set at minimal values due to the variable nature of loading directions in different applications. The product also boasts an impressive dynamic torsional moment load capacity (Mt), further attesting to its strength and reliability. Weighing at 0.3 kg/meter, the Bosch Rexroth LINEAR-SET LSFDR1-12-WV-900 is lightweight yet durable enough to support demanding applications while providing smooth and accurate linear movement.
