TORQUE RESISTANT BUSHING KBDRC1-16-WV-400

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDRC1-16-WV-400 (R072001680) is a high-precision component designed for self-supporting, torsionally stiff guides with a single shaft. This torqueresistant compact linear bushing is engineered without a seal and includes a standard length precision steel shaft with machined ball guide grooves. The product is ideal for applications requiring precise linear motion with a resistance to torsional forces. The KBDRC1-16-WV-400 features hardened steel bearing plates and balls made of rolling bearing steel, ensuring durability and a smooth operation. The adjusting screw is also made from hardened steel and comes preset to zero clearance, allowing for fine-tuning to achieve the desired fit. A steel lock nut secures the adjustment in place, while the ball retainer and outer sleeve are constructed from either PA or POM materials. This model has been designed to accommodate shaft diameters as specified by Bosch Rexroth standards, with two ball guide grooves starting from certain shaft diameters to enhance stability and load distribution. The dynamic load capacity of this model is indicated as minimal values due to varying loading directions, while the static load rating ensures reliable performance under stationary forces. The dynamic torsional moment load capacity further attests to its robustness in applications subject to rotational forces. The linear bushing operates efficiently within a permissible ambient temperature range of -30°C to +80°C and can handle maximum acceleration as well as high linear speeds without compromising performance. With an outer diameter of D=16mm and weighing 0.1 kg/m, it offers a compact solution for space-sensitive designs without sacrificing functionality or load-bearing capabilities.
