TORQUE RESISTANT BUSHING KBDR1-30-WV-2000

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDR1-30-WV-2000 (R069603088) is a high-precision component designed for self-supporting, torsionally stiff guides with a single shaft application. This torque-resistant linear bushing is notable for its ball guide grooves and the inclusion of a precision steel shaft that facilitates the transfer of torques. The shaft diameter 'd' ensures compatibility with standard lengths as per provided tables, while the absence of a seal indicates this model's suitability for environments where sealing is not critical. The KBDR1-30-WV-2000 is constructed with durable materials, including a ball retainer and outer sleeve made from either PA or POM, hardened steel bearing plates, and balls crafted from rolling bearing steel. These materials contribute to the bushing's robustness and longevity. Additionally, it features an adjusting screw set to zero clearance for precise control and a steel lock nut to maintain adjustments. With regards to technical specifications, this model boasts impressive load capacities that are minimal values due to the variable nature of loading directions. It has a dynamic load capacity 'C', static load rating 'C', and dynamic torsional moment load capacity 'Mt', ensuring it can handle significant forces during operation. Its design allows for maximum permissible linear speed 'vmax' and operates within a temperature range from minimum to maximum degrees Celsius. The outer diameter 'D' aligns with the requirements for specific applications, while its mass 'm' in kg/m provides an understanding of its weight, which is crucial for design considerations in various systems. As part of the Torque Series Productgroup ID, this linear bushing format is closed-type, offering additional protection against contaminants. Overall, the Bosch Rexroth TORQUE RESIST.BUSH KBDR1-30-WV-2000 serves as an essential component in linear motion applications requiring high torque resistance and precision movement.
