TORQUE RESISTANT BUSHING KBDR1-30

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth TORQUE RESIST.BUSH KBDR1-30 (R069603000) is a high-quality component designed for self-supporting, torsionally stiff guides with only one shaft. This torque-resistant linear bushing is engineered without a seal and does not include a shaft, emphasizing its use in applications where such features are not required or are provided separately. The KBDR1-30 model stands out with its ball guide grooves and a shaft diameter 'd' that ensures smooth motion and reliable guidance. Its construction includes a ball retainer and outer sleeve made from durable materials such as PA or POM, while the bearing plates are crafted from hardened steel to withstand demanding conditions. The balls within the bushing are made of rolling bearing steel, known for its strength and longevity. This model is equipped with an adjusting screw also made of hardened steel, which allows for zero clearance setting, ensuring precision in operation. It comes complete with a steel lock nut to secure the assembly in place. The dynamic load capacity C and static load rating C signify minimal values due to the variable nature of loading directions. The dynamic torsional moment load capacity Mt further adds to the robustness of this bushing's performance. Designed for closed linear bushings formats, it can sustain maximum acceleration (amax) and operate within a wide range of permissible ambient temperatures, from -20°C up to 80°C. The KBDR1-30 has an outer diameter 'D' that fits standard mounting requirements, while its maximum permissible linear speed (vmax) accommodates rapid motion within systems. Despite these capabilities, it maintains a moderate weight that contributes to efficient system design without compromising on strength or performance. In summary, the Bosch Rexroth TORQUE RESIST.BUSH KBDR1-30 (R069603000) is an essential component for creating precise and sturdy linear motion systems where single-shaft support with torsional rigidity is required. Its material composition and design specifications ensure reliable operation across various applications.
