SUPER LINEAR BUSHING KBA-O-25-DD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SUPER LINEAR BUSH (R067122540) is a high-precision linear motion component designed to provide smooth, accurate travel and an extended service life in various applications. This open linear bushing comes equipped with two seals and features the Super LB A with self-alignment capability, accommodating shaft deflection and misalignment up to a certain degree. It is suitable for use on fully supported shafts where other linear guides might experience warping due to suboptimal substructures. The SUPER LINEAR BUSH boasts steel bearing plates with precisely machined ball guide grooves and optimized ball lead-in chamfers, ensuring exceptionally smooth travel. The bushing's design allows for high travel speeds of up to 5 meters per second and can cope with maximum accelerations as specified by the manufacturer. It also includes integrated wiper seals that prevent contaminants from entering the bushing, thus eliminating the need for initial lubrication. Constructed from durable materials, the ball retainer and outer sleeve are made of either PA or POM, while the balls themselves are crafted from rolling bearing steel. This combination of materials ensures reliable performance across a range of operating conditions. The product supports a permissible ambient temperature range from -30°C up to +80°C. The dynamic load capacity and static load rating are provided by Bosch Rexroth for loads applied in the main direction, ensuring that users can accurately determine suitability for their specific application needs. Additionally, this model has a friction coefficient range provided by Bosch Rexroth that varies depending on load conditions. With a weight of 0.18 kg and dimensions tailored to fit specific requirements (including radial clearance options), the SUPER LINEAR BUSH is versatile enough to meet diverse industrial demands while maintaining high performance standards. Bosch Rexroth's commitment to quality is evident in their provision of detailed specifications such as breakaway force, maximum permissible speed, service life expectancy under varying travel distances without failure, and frictional characteristics under different operating scenarios.
