STANDARD LINEAR BUSHING KBM-80-D

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth STD.LINEAR BUSHING KBM-80-D (R060108010) is a high-performance standard linear bushing designed for demanding applications. This closed-type linear bushing features a rugged all-metal design with a steel ball retainer, making it suitable for harsh environments and heavy contamination. Its construction includes many pockets that act as lubricant reservoirs, allowing for extended lubrication intervals or even lubrication for life. The KBM-80-D is equipped with one seal and has been engineered to accommodate self-supporting shafts. The balls are crafted from rolling bearing steel, ensuring durability and smooth motion. The product is particularly well-suited for use in challenging conditions such as woodworking, foundries, and cement plants due to its ability to collect dirt and prevent jamming of the bushing. The outer sleeve is hardened and ground to provide a precise fit, while the rows of balls within the bushing ensure consistent load distribution and smooth linear movement. The product's design does not include wiper seals but comes with integrated steel retaining rings which allow operation at higher temperatures when used with shaft diameters 80 mm and above. For technical specifications, the KBM-80-D offers a maximum dynamic load capacity (Cmax), which varies based on total travel distance, with adjustments provided for different travel lengths. It also features a breakaway force requirement and can operate within an ambient temperature range of -30°C to +80°C. The friction force is noted along with minimum static load capacity (Cmin) and maximum static load capacity (Cmax). With a weight of 0.8 kg, this linear bushing provides robust performance in industrial settings where reliability is crucial. In summary, the Bosch Rexroth STD.LINEAR BUSHING KBM-80-D (R060108010) stands out as a durable solution for linear motion requirements in environments where contaminants are prevalent and maintenance intervals need to be minimized.
