LOCATING RING D=9/5 ...

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LOCATING RING (R039660548) is a mechanical accessory designed for linear axes applications, specifically as a centering ring within the product group of mechanical accessories. This component is integral for ensuring precise positioning and positive locking when attaching customer-specific components to a frame. The LOCATING RING has an outer diameter denoted as D=9/5, indicating its size and compatibility with certain equipment dimensions. Crafted from steel, the ring offers durability and reliability in various operational conditions. It is engineered to create a positive-locking connection that can be reproduced accurately, enhancing the stability and alignment of the attachments it secures. The inclusion of this ring in assembly processes ensures that mounted components remain firmly in place, providing an extra layer of security and precision. The design specifications include a tolerance level for size E and an exact weight measurement, ensuring that it meets stringent quality standards and fits seamlessly within designated Bosch Rexroth linear axis systems. The nominal size and other dimensional tolerances such as the C prefix/suffix and D prefix/suffix are meticulously defined to ensure compatibility with corresponding parts. In summary, the Bosch Rexroth LOCATING RING is an essential accessory for users requiring precise mounting solutions in linear motion applications. Its robust construction from steel material guarantees longevity and consistent performance in securing customer attachments to frames with excellent reproducibility.
