CONNECTING PLATE CKK 25-200 L BG

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CONNECTING PLATE CKK 25-200 L (R037560010) is a robust mechanical accessory designed for linear axes, specifically tailored to enhance the functionality and integration of CKK series components. This product is a key element in the assembly of precision linear motion systems, offering a reliable means to attach various attachments using sliding blocks. The connection plate allows for the convenient lubrication of both the ball rail system and the ball screw assembly, ensuring smooth operation and longevity of the linear motion setup. With a nominal size that fits the specified dimensions, this connection plate comes complete with mounting accessories required for secure fastening to carriages. It is crafted to meet the high standards of quality and performance that are characteristic of Bosch Rexroth's engineering components. Size A of this product denotes its compatibility with certain system requirements, while Size E indicates its classification within Bosch Rexroth's product group ID for mechanical accessories. Additionally, Sizes H and D further define its physical dimensions and suitability for different configurations within linear axis applications. The weight specification ensures that users can account for load considerations when planning their motion systems. Overall, the Bosch Rexroth CONNECTING PLATE CKK 25-200 L (R037560010) represents an essential component for those seeking to construct or maintain precise linear motion mechanisms with high reliability and ease of maintenance.
