CONNECTING PLATE CKK 12-90 L BG

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CONNECTING PLATE CKK 12-90 L (R037530010) is a meticulously engineered component designed to facilitate the integration and fastening of attachments using sliding blocks. This product belongs to the mechanical accessories category for linear axes, specifically tailored for use with Bosch Rexroth's CKK series. The connection plate is not only instrumental in securing attachments but also enables the lubrication of both the ball rail system and the ball screw assembly through its design, ensuring smooth operation and longevity of the linear motion system it supports. The R037530010 model boasts a robust construction with precise dimensions, including Size A for Productgroup ID, Size E represented twice indicating critical measurements, as well as multiple references to Size H and Size D, which are essential for compatibility and installation purposes. The outer diameter D is also specified under Size E, ensuring a perfect fit with corresponding components. This model's nominal size is an important specification that defines its suitability for various applications within linear motion systems. The assembly includes not only the connection plate itself but also mounting accessories necessary for secure attachment to carriages. These features make the Bosch Rexroth CONNECTING PLATE CKK 12-90 L an indispensable part of a linear axis setup, providing reliability and precision in motion control applications. The weight specification under Size C further informs users about the physical characteristics of this component, allowing for informed decisions regarding transportation and handling during installation.
