MODULE SMS-120-P10-200

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth MODULE SMS-120-P10-200 (R02681L004) is an ultracompact linear motion module featuring a threaded screw drive designed for efficient handling and simple positioning tasks. This module is particularly well-suited for electrification in cost-sensitive applications or as a replacement for pneumatic modules. With its small size, the SMS-120-P10-200 offers a maximum travel range that allows for precise movement control in confined spaces. The MODULE SMS-120-P10-200 has been engineered to handle maximum payloads effectively, with specific ratings for horizontal, vertical, and wall assembly orientations. The module width and height are tailored to integrate seamlessly into various setups, maintaining a compact footprint without sacrificing performance. The product group ID provides easy reference for system compatibility and accessory selection. Bosch Rexroth has equipped this module with options for motor attachments, including flange coupling or belt side drives compatible with conventional servo motors, available as separate accessories. This flexibility ensures that the MODULE SMS-120-P10-200 can be adapted to a wide range of application requirements. Performance characteristics such as maximum drive torque, acceleration (amax), total length (Lges), and maximum permissible linear speed (vmax) are specified to ensure optimal operation within its capabilities. The module also boasts impressive repeatability metrics, signifying its ability to return to a position with precision—a critical factor in automated processes. The SMS series includes detailed information on permissible overhangs in various installation orientations—horizontal, vertical, and wall assembly—to guide users in achieving the best setup without compromising safety or functionality. These specifications are essential when considering the mechanical loading conditions during operation. Overall, the Bosch Rexroth MODULE SMS-120-P10-200 is a versatile and reliable choice for those needing precise linear motion control in compact automation systems. Its thoughtful design caters to quick availability from stock and ease of integration into existing setups while offering customization options through preconfigured variants and motor attachment accessories.
