MODULE SMS-080-P20-1000

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth MODULE SMS-080-P20-1000 (R02681H070) is an ultracompact, screw-driven module designed for efficient handling and simple positioning tasks. This small module is particularly suitable for applications that require electrification in cost-sensitive areas or as a replacement for pneumatic modules. With its maximum travel range of 1000 mm, it provides versatility for a variety of uses. The MODULE SMS-080-P20-1000 offers a high level of functionality and performance with options for motor attachments, such as flange coupling or belt side drive compatible with conventional servo motors. These motor attachments are available as separate accessories, allowing for customization based on the application's requirements. This module boasts impressive specifications, including a maximum payload capacity in both horizontal and vertical orientations. It is engineered to handle maximum payloads efficiently while maintaining stability and precision. The product group ID ensures that users can identify the correct module variant quickly and easily. The dimensions of the MODULE SMS-080-P20-1000 include a specific module width and height, contributing to its compact design. Its lead system and permissible overhangs (A, B, C) at maximum payload capacities are detailed in the Bosch Rexroth catalog R, which provides comprehensive information regarding overhangs combined with payload levels for various installation positions including vertical, horizontal, and wall assembly. In terms of performance capabilities, this module can achieve high acceleration (amax), maximum permissible linear speed (vmax), and features a specified max drive torque. The repeatability rate indicates the precision level that this module can consistently achieve. Lastly, the nominal size SMS designation highlights its classification within Bosch Rexroth's range of small modules. The total weight of the MODULE SMS-080-P20-1000 is provided to aid in planning for installation and integration into systems where weight considerations are crucial.
