GEAR MOTOR AZMF-12-019UQR12ML-S0018

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZMF-12-019UQR12ML-S0018 (9511290029) is an external gear motor designed to convert hydraulic energy flow and pressure into mechanical energy, delivering torque and rotational speed with high efficiency. This efficiency stems from the motor's pressure-dependent gap sealing and high-precision manufacturing technology. The model AZMF-12-019UQR12ML-S0018 boasts a wide speed range, making it suitable for diverse applications that require varying speeds. This gear motor is engineered for durability, with an extremely long service life of approximately 10 million actuations, and features slide bearings that are capable of handling high loads. It offers versatility through its optional reversible version, which supports both 2- and 4-quadrant operation. The consistent quality of the motor is a result of Bosch Rexroth's large-volume production processes. With a geometric displacement size of 19 cm³/rev and a maximum rotational speed guideline, this motor ensures optimal performance for a variety of tasks. It comes with a straight shaft SAE J 500 short configuration, an SAE J 518 A bolt flange on the front cover, and UNF threads with SAE O-ring line connections for secure installation. The housing material is aluminum for a lightweight yet robust construction. The AZMF-12-019UQR12ML-S0018 has been designed to be birotational with a bearing diameter of 22 mm and features an axial drain port on its rear cover. Its corrosion-resistant version with pinned connections ensures longevity even in harsh conditions. This model has standard noise levels during operation, adhering to industry standards for workplace comfort. The external gear unit function is specifically as a motor within the system it integrates into, ensuring reliable mechanical power generation. With its weight at approximately 6 kg and maximum flow capacity at 45 l/min, this Bosch Rexroth gear motor stands out as a powerful component in hydraulic systems demanding precision and reliability.
