GEAR MOTOR AZMF-12-011UQR12ML-S0022

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZMF-12-011UQR12ML-S0022 (9511290014) is an external gear motor renowned for its capability to efficiently convert hydraulic energy flow and pressure into mechanical energy, specifically torque and rotational speed. This model boasts a geometric displacement of 11.9 cm³/rev and is designed with a straight shaft compliant with SAE J 744 standards, making it suitable for a broad range of applications. The motor features a birotational direction of rotation, allowing it to be used in both 2- and 4-quadrant operations. Constructed from aluminum with slide bearings capable of handling high loads, the AZMF-12-011UQR12ML-S0022 ensures durability and an extended service life of approximately 20 million actuations. It is equipped with an SAE J 518 A bolt flange on the front cover and utilizes thread UNB along with SAE O-ring line connections for secure fittings. The rear cover includes an axial drain port, contributing to the unit's maintenance efficiency. This model has been engineered for optimal performance with a maximum rotational speed capacity of 4000 rpm and can operate under a maximum constant pressure of 280 bar. Its corrosion-resistant design features deviations from standard catalog specifications, as indicated by accompanying drawings, ensuring specialized application requirements are met. The external gear motor maintains a standard noise level during operation, minimizing acoustic disturbances in the working environment. With a weight of approximately 3.6 kg and the ability to handle a maximum flow rate of up to 40 l/min, this motor is poised for use in various general industrial applications where reliable hydraulic power conversion is essential. The NBR sealing material further enhances the unit's robustness against potential leaks and environmental factors.
