HYDRAULIC GEAR PUMP AZPG-22-063RDC15MB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPG-22-063RDC15MB (9510490050) is a high-efficiency external gear pump designed to convert mechanical energy into hydraulic energy with minimal heat loss. This unit features pressure-dependent gap sealing and high-precision manufacturing technology, ensuring a long service life and consistent quality, which is especially important in large-volume production. With a geometric displacement of 63 cm³/rev, the pump can achieve a maximum rotational speed. The AZPG-22-063RDC15MB is built with durable aluminum housing and NBR sealing material for corrosion resistance. It incorporates slide bearings capable of handling high loads, making it suitable for demanding applications. The drive shaft follows the SAE J 744 T DP spline shaft standard, while port connections are made through an SAE Split flange with UNC thread or alternatively threaded ports. Designed for general application use, this pump comes with a standard noise level and features a clockwise rotation (cmrev). The front cover includes an SAE J 518 B bolt flange, while the rear cover is standard. It supports a maximum intermittent pressure and has an external gear unit function as a pump. The bearing diameter stands at 40 mm. The Bosch Rexroth AZPG series model G external gear unit showcases remarkable capabilities in terms of flow and pressure conversion efficiency. With its weight of 8.5 kg, it can deliver a max flow rate of up to 100 l/min, making it an integral component in hydraulic systems requiring reliable and precise fluid power delivery.
