HYDRAULIC GEAR PUMP AZPG-22-045RDC15MB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPG-22-045RDC15MB (9510490047) is a high-efficiency external gear pump designed to convert mechanical energy into hydraulic energy with minimal heat loss. This unit features a clockwise rotation and is equipped with a spline shaft conforming to SAE J 744 T DP standards, ensuring compatibility with various drive systems. The pump's robust construction includes a SAE J 518 C bolt flange and an SAE split flange with UNC thread for secure port connections. With its advanced pressure-dependent gap sealing and precision manufacturing technology, the AZPG-22-045RDC15MB achieves consistent high quality and performance. It also boasts slide bearings capable of handling high loads, enhancing the pump's durability and extending its service life. The front cover integrates seamlessly with the SAE J 518 B bolt flange, while the rear cover comes as a standard feature. This model has a maximum rotational speed that complements its size and geometric displacement of 22 cm³/rev, ensuring optimal fluid flow. The sealing material used is NBR, which is known for its resilience and compatibility with numerous fluids. Additionally, the unit version of this pump has a bearing diameter of 32 mm. Designed for general applications, the AZPG-22-045RDC15MB pump's housing is made from corrosion-resistant aluminum, contributing to its longevity even in challenging environments. Its noise level is within standard parameters, making it suitable for use in settings where noise reduction is desirable. Overall, this external gear unit functions primarily as a pump and weighs approximately 8 kg. It can handle a maximum intermittent pressure effectively while maintaining a max flow rate that meets system requirements. Its combination of features makes it an ideal choice for those seeking reliable hydraulic performance without compromising on quality or efficiency.
