HYDRAULIC GEAR PUMP AZPG-22-036RDC15MB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPG-22-036RDC15MB (9510490045) is a high-efficiency external gear pump designed for converting mechanical energy into hydraulic power with minimal heat loss. This unit features pressure-dependent gap sealing and precision manufacturing technology, ensuring optimal performance. It is equipped with slide bearings capable of handling high loads and offers drive shafts that conform to ISO or SAE standards, as well as customer-specific requirements. The pump promises consistent quality derived from large-volume production processes and is built for longevity with its robust aluminum housing and NBR sealing material. With a geometric displacement size of 22 cm³/rev, the AZPG-22-036RDC15MB ensures a reliable flow rate. Its port connections include an SAE J 518 C bolt flange front cover and an SAE split flange with UNC thread line connections for versatile integration into various hydraulic systems. The unit's maximum rotational speed supports dynamic operation, while the standard noise level makes it suitable for environments where noise reduction is beneficial. The pump's clockwise rotation direction, coupled with a spline shaft adhering to SAE J 744 T DP standards, allows for seamless torque transmission. It also features a corrosion-resistant version with pinned construction to enhance durability in challenging conditions. With a bearing diameter of 45 mm and a maximum intermittent pressure capacity, the Bosch Rexroth AZPG-22-036RDC15MB pump is engineered to meet rigorous demands while providing efficient and reliable service in general application settings. The unit weighs in at 8.9 kg and can deliver a maximum flow rate of 36 l/min, making it an effective solution for various hydraulic requirements.
