HYDRAULIC GEAR PUMP AZPG-22-032RDC15MB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPG-22-032RDC15MB (9510490044) is a high-efficiency external gear pump designed to convert mechanical energy into hydraulic energy with minimal heat loss. This unit is characterized by its pressure-dependent gap sealing and precision manufacturing, which contribute to its high performance. It features slide bearings capable of handling high loads, ensuring durability and a long service life. The drive shaft follows the SAE J 744 T DP standard, while the rear cover is standardized for consistent quality. With a geometric displacement size of 32 cm³/rev, the AZPG-22-032RDC15MB operates with a clockwise rotation and has a spline shaft that adheres to SAE standards. The pump's housing is made of corrosion-resistant aluminum, with port connections that include an SAE split flange with UNC thread for secure line connections. The front cover integrates an SAE J 518 C bolt flange design. This model boasts standard noise levels during operation, making it suitable for environments where noise reduction is beneficial. It has been designed for general application use where external gear units are required. The bearing diameter measures at 40 mm, supporting the robustness of the unit. The pump's maximum intermittent pressure capability ensures reliable performance under varying conditions, while the NBR sealing material provides effective sealing against fluid leakage. With a weight of approximately 7 kg, this external gear pump can achieve a maximum flow rate of 60 l/min, making it versatile for various hydraulic applications. Its design reflects Bosch Rexroth's commitment to quality and efficiency in their product offerings.
