HYDRAULIC GEAR PUMP AZPF-12-019LRR12MB

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPF-12-019LRR12MB (9510290128) is an external gear pump designed for efficient conversion of mechanical energy into hydraulic energy, characterized by its high precision and pressure-dependent gap sealing that minimizes heat losses. This particular model boasts a counter-clockwise rotation and features a robust spline shaft in accordance with SAE J 499 T DP standards. It is mounted using an SAE J 518 A bolt flange and utilizes thread UNF for line connections, complemented by SAE O-ring seals to ensure secure and leak-proof operation. The AZPF-12-019LRR12MB pump is built to withstand high loads, thanks to its durable slide bearings and standard cast iron rear cover. The aluminum housing material contributes to the unit's overall resilience and longevity. With a geometric displacement size of 19 cm³/rev, this pump can achieve a maximum rotational speed specific to its design parameters. This model includes NBR sealing material and is noted for its corrosion resistance, which extends the service life even in demanding conditions. The noise level remains standard for this type of gear unit, making it suitable for environments where noise reduction is important but not critical. The front cover integrates seamlessly with the SAE J 518 A bolt flange design. The Bosch Rexroth AZPF series pumps are engineered with a focus on consistent quality derived from large-volume production techniques. The maximum intermittent pressure that this unit can handle is indicative of its robust performance capabilities. With a bearing diameter of mm (specific value not provided), the external gear unit function is optimized as a pump with a weight of . kg (specific value not provided). The maximum flow rate that can be achieved by this model is . l/min (specific value not provided), making it versatile for various hydraulic applications requiring precise fluid control.
