BASE PLATE ECOSHAPE ESD

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth BASE PLATE ECOSHAPE ESD (3842559345) is a versatile and robust component designed for securing frames to various surfaces including walls, floors, table tops, and strut profiles with a mm slot. This base plate is part of the EcoShape modular system and is crafted from diecast zinc, ensuring both durability and compatibility with EcoShape round tubes. It simplifies installation by eliminating the need for additional connectors, thanks to its direct fastening capabilities. Equipped with an antitorsion element that can be effortlessly broken off if required, this base plate ensures stability and precision in mounting. The reference load it can support during profile installation is Nm in both lengthwise and crosswise directions. However, when mounted on other materials, the load values may vary based on the properties of those surfaces. The BASE PLATE ECOSHAPE ESD serves as a foundational element for creating custom structures within an ESD-safe environment. Its non-slip design makes it suitable for constructing flow racks and stands that require a secure grip. Additionally, it includes a D-ring feature that facilitates the design of simple tool holders through spring hooks or snap hooks for attaching tools. This product also comes with a stopper DL, N designed to halt material shuttles at just one point ergonomically. It offers an all-purpose attachment option suitable for different round tubes and profile cross-sections while providing a stopper tension path of mm. The packaging unit of this Bosch Rexroth base plate includes all necessary fastening materials such as chipboard screws and recommended accessories like countersunk screw ISO Mx.; T-nut Fastening material x chipboard screw x are also provided to ensure seamless integration into various applications requiring reliable fastening solutions in electrostatically sensitive environments.
