CURVE 90+ VERT AL 90° R500

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CURVE 90+ VERT AL 90° R500 (3842559127) is a high-quality vertical curve designed for seamless integration into conveyor systems requiring transitions from horizontal to ascending sections and vice versa. This component boasts an aluminum profile that is anodized for durability and resistance to corrosion, ensuring long-term reliability in various operational environments. The profile connectors are made of galvanized steel, while the cross connectors are constructed from diecast aluminum. For larger sizes, the support profile is fabricated from non-rusting steel, providing additional strength and stability. This particular model features a deflection angle that facilitates smooth directional changes within the conveyor system, enhancing efficiency and reducing wear on conveyed materials. It comes fully assembled with all necessary fastening materials for mounting to the AL section profile included in the scope of delivery. This ensures a quick and easy installation process. The CURVE 90+ VERT AL 90° R500 is also equipped with a slide rail, and its length calculation size 'b' and dimension 'A' are critical for proper fitment and function within the system it is designed for. Customers seeking additional versions or modifications can reach out directly to Bosch Rexroth's modification department to explore customized solutions tailored to their specific needs. In summary, this vertical curve unit is a versatile and essential component for optimizing conveyor system performance where elevation changes are required. Its robust construction and thoughtful design underscore Bosch Rexroth's commitment to engineering excellence in facilitating efficient material handling processes.
