FRAME PROFILE 30X30 WG30 20X6070MM
Manufacturer: Bosch Rexroth
Material #: 3842557227
Model : FRAME PROFILE 30X30 WG30 20X6070MM
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth FRAME PROFILE 30X30 WG30 (3842557227) is a versatile and robust solution designed for constructing protective barriers with woven wire grilles. This aluminum anodized profile is tailored to facilitate the direct fastening of woven wire grilles in its specialized profile slot, ensuring a secure and stable structure. The profile also accommodates surface elements which can be fastened using spring clamping elements, enhancing the rigidity and durability of the assembled barrier.
This product features a modular dimension B that corresponds to x supports, enabling customization according to specific project requirements. The inclusion of a cover cap enhances the profile's appearance while also serving to prevent injuries by covering exposed edges. The FRAME PROFILE 30X30 WG30 requires profile machining for connection, utilizing a central bolt for assembly which ensures a streamlined and efficient construction process.
With its moment of resistance in the y-direction (Wy) and area moment of inertia in y-direction (ly), as well as its moment of resistance in the x-direction (Wx), this frame profile is engineered to withstand significant loads and stresses. It offers an excellent balance between weight and structural integrity, making it suitable for various applications where safety barriers are essential.
The delivery unit includes standard length profiles with a mass (m) specification provided, ensuring that customers receive consistent quality and dimensions for their projects. The area moment of inertia in x-direction (lx) further defines the product's specifications, ensuring that engineers can accurately calculate load-bearing capacities.
To complete installation, required accessories such as central bolts, woven wire grilles, and spring clamping elements are necessary. These components work in tandem with the FRAME PROFILE 30X30 WG30 to create secure installations that meet safety standards while maintaining aesthetic appeal.
$2,908.53 USD
Availability: 5 In Stock
Available for immediate shipmentQty: Delivered as early as November 15, 2024 when ordered in
