CURVE 120+ HOR STS 90° R700

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CURVE 120+ HOR STS 90° R700 (3842557061) is a high-quality horizontal sliding curve designed to facilitate a smooth directional change in conveyor systems where space constraints or product handling requirements make the use of a curve wheel impractical or impossible. This component offers an efficient solution for altering the path of a chain in material handling and automation applications, with a deflection angle that ensures seamless integration into existing conveyor setups. The CURVE 120+ HOR STS 90° R700 is crafted from non-rusting steel, ensuring durability and longevity even in demanding industrial environments. The effective sliding rail length and actual chain length are tailored to meet specific system requirements, ensuring compatibility and optimal performance. For unique applications, additional versions can be requested through Bosch Rexroth's modification department, providing customization options to meet precise conveying needs. Included with the sliding curve is all necessary fastening material for secure mounting to STS section profiles. The product arrives fully assembled for ease of installation, minimizing downtime and simplifying the integration process. Users will need to perform a slide rail length calculation to ensure proper sizing (dimension A), which is crucial for maintaining the efficiency and reliability of the conveyor system. This sliding curve unit represents an essential component within the broader spectrum of Bosch Rexroth's advanced conveying solutions, engineered to uphold the highest standards of functionality and performance. Its robust construction paired with precise engineering makes it suitable for various applications requiring horizontal directional changes in automated material transport systems.
