$2,306.84 USD
Product Surcharge: $92.28 USD
Status: This product is temporarily out of stock.
Qty: Delivered as early as May 22, 2025 when ordered in
| Safety guard above the lifting plungers for the PE 5/OC and PE 5/OC-T. Refer to the assembly instructions for the installation dimensions. |
| Note: Do not walk on the protective covers: Note: Do not walk on the protective covers |
| Protective covers for PE 5/OC-T and PE 5/OC-T with VE 5/OCD-300 or VE 5/OCD-1000 |
| Data Sheet | Download Data Sheet |
| 3D CAD | Download 3D CAD |
| Cover cap | yes |
| Productgroup ID | 2 |
| Material | Aluminum |
| Weight | 7.9 |
| Notice | b = Track width of the positioning unit in the direction of transport |
| Scope of delivery | Incl. protective sleeves (A and B) and fastening material |
| Delivery information | Not assembled |
| Length in direction of transport [lT] | 1040 |
| Track width [b] | 845 |
| Material information | Cover: Aluminum,Protective sleeves: PA |
