CUBIC JOINT 40/2 SILVER SET
Manufacturer: Bosch Rexroth
Material #: 3842549867
Model : CUBIC JOINT 40/2 SILVER SET
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CUBIC JOINT 40/2 SILVER SET (3842549867) is a high-quality cubic connector set designed for the torsion-resistant corner connection of profiles with equal cross sections. It is part of the designLINE series, featuring a special silver paint finish corresponding to RAL color standards, which provides an exceptionally high-quality appearance. The connectors are crafted from die-cast aluminum and painted to achieve a white aluminum color (RAL 9006), ensuring both durability and aesthetic appeal.
The set includes cover caps made of signal gray polypropylene (PP) to cover the openings, although it's important to note that while the cubic connector itself creates a conductive connection suitable for electrostatic discharge (ESD) sensitive environments, the included cover caps are not ESD-compatible. For applications requiring full ESD protection, users may opt for black PP cover caps available as recommended accessories.
Installation is straightforward with screw fitting on the profile using self-tapping screws provided in the kit. The fastening material consists of steel screws that have been galvanized for corrosion resistance. With a bending moment specification of Mk = 160 Nm, this connector set can handle significant mechanical loads, making it suitable for robust structural applications.
The product comes with all necessary fastening materials, including one cubic connector designLINE and one D-type cover cap. Dimensions and number of outlets are tailored to fit specific profiles slots seamlessly. The weight of this particular model is light at just 0.27 kg, allowing for easy handling during assembly.
Overall, the Bosch Rexroth CUBIC JOINT 40/2 SILVER SET offers a combination of strength, aesthetics, and functionality for constructing frames and structures in various applications where design and mechanical integrity are paramount.
$14.84 USD
Availability: 28 In Stock
