RING D50

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth RING (3842548131) is a versatile component designed for use with the EcoShape tubular framing system. This steel, nickel-plated ring is an essential part for creating simple tool holders, enabling the efficient organization of tools within a workspace. It can be easily integrated into various structural designs due to its compatibility with DL and N tube clamps, which allow for oblique positioning of up to 45 degrees. Additionally, the RING D50 serves as a base plate that can be directly fastened onto walls, floors, table tops, and strut profiles featuring a 10 mm slot. The innovative design of this base plate eliminates the need for additional connectors. The product also includes an antitorsion element with a centering lug that can be broken off if necessary. This feature ensures stability and resistance against twisting forces during installation. The reference load during profile installation is specified at 200 Nm in both lengthwise and crosswise directions, although load values may vary when installed on different surface materials. Furthermore, this component is part of a broader system that includes items such as tube clips for attaching material shelves to round tubes at various angles; rubber feet designed for non-slip applications in flow racks and stands; and stoppers (DL, N) which provide an ergonomic solution to halt material shuttles at a single point on different round tubes and profile cross-sections with a stopper tension path of 10 mm. The Bosch Rexroth RING D50 is not only functional but also durable due to its steel construction and nickel plating. With a weight of 0.05 kg and packaged in appropriate units, this product ensures reliable performance in various applications within the EcoShape tubular framing system.
