HINGE D28L / D28L

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HINGE D28L (3842548126) is a versatile and robust component designed for the EcoShape tubular framing system. This hinge facilitates the construction of movable connections between round tubes or surface elements, enhancing the flexibility and functionality of structural designs. Constructed from high-quality aluminum, it is both lightweight and durable, ensuring longevity and reliability in various applications. With an unspecified opening angle, the HINGE D28L allows for a wide range of motion, making it ideal for creating doors, panels, or other pivoting structures within a framing system. The hinge is specifically tailored to mount onto DL round tubes as well as surface elements, providing a secure and stable joint that can be easily assembled. The product comes with all necessary fastening materials including cylinder head screws (ISO Mx), T-nut grooves (M), grooved pins (ISO x), washers (DIN A), and cover caps to ensure a complete installation package. Its ESD compliance indicates suitability for use in electrostatically sensitive environments, which is critical in protecting electronic components from static discharges. Dimension A refers to the size of the hinge that attaches to profiles or surfaces, while Dimension B likely corresponds to the moving arm of the hinge. The exact dimensions are not specified here but are critical for ensuring compatibility with existing systems and components. The weight of the hinge is also not mentioned but would be an important consideration for design specifications regarding load-bearing capacity. Overall, the Bosch Rexroth HINGE D28L (3842548126) offers a practical solution for constructing flexible joints within the EcoShape tubular framing system. Its ease of assembly and adaptability make it suitable for various applications where movable connections are required.
