CORNER BRACKET D28; 90°-270°; 15°

Manufacturer: Bosch Rexroth

Material #: 3842548123

Model : CORNER BRACKET D28; 90


***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CORNER BRACKET D28; 90°-270°; 15° (3842548123) is a versatile and robust component designed for the EcoShape tubular framing system. This corner bracket facilitates easy adjustment within a swivel range of 90° to 270°, allowing for the construction of swiveling applications. Its design includes a DL swivel bearing which is capable of axial shifting along the D28 or D30L round tube, with the retaining ring setting the end position firmly. The bracket's additional thread feature enables flexible bracket adjustment to meet various application needs. The product is intended for self-assembly and includes a DL swivel bearing that can be cut to length according to specific requirements, a D bushing, and a DL retaining ring as part of its assembly components. This corner bracket is constructed from die-cast zinc, ensuring durability and strength. It comes with fastening material that includes M8 cylinder head screws in accordance with ISO standards and M8 hexagon nuts conforming to DIN specifications. The packaging unit denotes that this product is ESD safe (Electrostatic Discharge), making it suitable for use in environments where static electricity must be carefully managed. The weight of the component is noted as . Scope (likely indicating that specific weight information should be checked), and it comes ready with all necessary fastening materials for immediate installation upon delivery.

$187.40 USD

($9.37 USD/Each)

Sold in packs of 20
Availability:  8  In Stock
  Add to Cart
Available for immediate shipment

Qty: Delivered as early as December 24, 2024 when ordered in
