STOP GATE VE 1/D

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth STOP GATE (3842547758) is a pneumatic stop gate designed to halt workpiece pallets on a conveyor system securely and reliably. When the pressure is released, a spring mechanism ensures that the stop gate closes, stopping the pallet in its tracks. This feature is particularly crucial for maintaining production safety by preventing unintended movement of items on the conveyor. Adaptable pneumatic damping allows for customization based on the weight of the workpiece pallet, accommodating a minimum weight specification and managing a permissible total load in accumulation operation. The stop gate operates efficiently with a conveying speed of up to 9 meters per minute and is suitable for dry room environments. The STOP GATE VE 1/D comes fully assembled with all necessary fastening materials for mounting onto the conveyor section. It also includes a pneumatic elbow fitting of push-lock type for easy installation. To meet various setup requirements, it can be attached to either the right (A) or left (B) inside section profile. For optimal performance, this model requires connection to compressed air with specific maximum and minimum pressures detailed in its specifications. Additionally, while it has a nominal speed range listed, it's important to note that proper functioning depends on pairing with an appropriate pneumatic valve – specifically recommended is the Rexroth M valve with a nominal flow rate of 400 liters per minute. In summary, the Bosch Rexroth STOP GATE VE 1/D offers robust functionality for stopping workpiece pallets within an automated conveyor system. Its design emphasizes safety and adaptability to various weights and operational speeds, ensuring seamless integration into existing production lines.
