CONSOLE 120+ STS LEG SET

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CONSOLE 120+ STS LEG SET (3842546660) is a robust support system designed to facilitate the mounting and stabilization of chain conveyors. This leg set is part of the STS Holder series and is crafted from non-rusting steel, ensuring durability and longevity in various operational environments. It features a minimalistic design with few screwed connections, which simplifies assembly and maintenance. The product is engineered to enhance cleanliness with its easy-to-clean design that includes ample draining surfaces, making it suitable for applications where hygiene is paramount. The leg set incorporates mm profile slots within the workpiece pallet frame, allowing for straightforward attachment of workpiece supports. These supports are versatile as they can be utilized alongside AL sections for added flexibility. The CONSOLE 120+ STS LEG SET stands out due to its quick and easy leg set adjustments attributed to intelligent product details. For secure installation, this leg set includes drilling aids on the underside, which serve as guides for accurately doweling the leveling feet. The scope of delivery includes all necessary fastening materials, although the product is delivered unassembled. When constructing the support system, separate components such as various foot versions (A, B, C), tube E, flange F, and holder G are assembled to create a sturdy base for chain conveyors. The holder G can be directly connected to strut profiles and is compatible with both ascending and descending conveyor sections up to a certain incline degree. For systems involving significant speed, accumulation behavior, or weight, it's recommended that supports are spaced approximately every 2 meters apart. Cross reinforcements become essential when using feet types B and C due to stability requirements. In summary, the Bosch Rexroth CONSOLE 120+ STS LEG SET provides an efficient solution for supporting motor drives in conveyor systems with its adaptable design that accommodates various mounting scenarios while ensuring ease of maintenance and cleanliness.
