JOINT 45X45 LOCKABLE

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth JOINT 45X45 LOCKABLE (3842546564) is a versatile and robust component designed for creating adjustable or rigid profile connections in various applications. This lockable joint is compatible with both joint x and joint x support, ensuring a wide range of usability. Engineered for handling high loads, it can sustain up to Nm in the swivel direction, making it suitable for demanding environments where stability and strength are paramount. The JOINT 45X45 LOCKABLE features a Hirth toothed coupling which provides positive interlocking, ensuring secure connections that resist loosening under vibration or dynamic forces. Its swivel range allows for easy adjustment within the modular dimensions, and the product is marked with a graduation for effortless detection of the adjustment angle. For convenience in assembly and adjustments, this joint can be clamped using either a clamping lever or screw. The design eliminates the need for profile finishing thanks to its self-cutting screw which facilitates end face to end face connections directly. Constructed from diecast zinc, the JOINT 45X45 LOCKABLE is not only durable but also has an ESD-safe design, making it suitable for use in electro-sensitive environments. It measures x in dimensions and fits perfectly into a modular dimension setup. The product's bending moment capacity further contributes to its robust performance. Included in the scope of delivery are all necessary fastening materials, which are made from galvanized steel for enhanced corrosion resistance. These include flange head screws Mx and T-nut groove M screws Sx tailored for Profile slot . Additionally recommended accessories such as clamping levers further augment this product's functionality. Overall, the Bosch Rexroth JOINT 45X45 LOCKABLE offers reliable performance with easy adjustability and secure locking capability, making it an essential component for constructing stable frameworks that require precise angular positioning.
