CHAIN PLATE 160+ FLAT

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth CHAIN PLATE (3842546093) is a critical component designed for flat conveyor chain systems, offering a reliable means of transporting products either directly or via workpiece pallets. This particular model is ideal for use with steel wear pads, and its dark color minimizes visual impairments on the chain surface. The chain plate is capable of operating on ascending or descending sections up to certain angles, which should be verified through product testing. It also supports accumulation operation under specific conditions. This product comes in various sizes including 160, with each size allowing for easy replacement of the chain plate. The material used in manufacturing the chain plate is POM (Polyoxymethylene), known for its strength and durability. The design includes a mold cavity in sizes 160 to accommodate a flat M6 hexagon nut and a centering aid on the underside of the chain plate in certain sizes to facilitate precise alignment. The Bosch Rexroth CHAIN PLATE has been engineered to permit low-vibration transport of small parts and allows for accumulation operation due to covered chain links. Its maximum tensile force capacity stands at 1250 N, ensuring robust performance in various applications. For customization, the flat chain links can be drilled up to 8 mm without interference from other contours in the conveyor system, allowing simple attachment of customer-specific structures. In terms of compliance, materials used meet both EU Regulation 10/2011 and FDA CFR 21 standards. Additionally, this model is available in an ESD version for applications requiring electrostatic discharge protection. With its patented design contributing to extremely quiet operation, the Bosch Rexroth CHAIN PLATE is an essential component for efficient and effective conveyor systems within various operational settings.
