WEDGE CHAIN 90+ 5L L2898
Manufacturer: Bosch Rexroth
Material #: 3842546086
Model : WEDGE CHAIN 90+ 5L L2898
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth WEDGE CHAIN 90+ 5L L2898 (Material Number: 3842546086) is a specialized conveyor chain designed for the secure transport of products across varying heights or distances where standard conveyor systems may not be suitable. This wedge chain is particularly useful for items that cannot be transported vertically due to their design, items with a center of gravity that prevents them from being moved up steep gradients using other chains, or those with sensitive surfaces that could be damaged by lateral or upper guides. It also ensures that products do not slip during vertical transportation and allows for transport without the need for synchronization.
The WEDGE CHAIN 90+ 5L L2898 boasts an extremely quiet operation due to its patented chain design. It comes fully assembled, including the chain pin and jointed bolts, ensuring ease of installation. The product is constructed from high-quality materials with the chain link made of POM, plates from TPE with Shore hardness A, a non-rusting steel chain pin, and a pivot pin made of PA. This makes it only suitable for dry operations.
The design includes lamellae available in two versions: one for products insensitive to pressure and another for those sensitive to pressure. However, it is important to note that the lamellae are not appropriate for transporting sharp-edged objects. The materials used in the WEDGE CHAIN meet EU and FDA regulations.
For assembly and disassembly purposes, an assembly module is required due to its intricate construction. While this wedge chain offers a versatile solution for product transportation, accumulation operation is not permitted with this system. Furthermore, there's a maximum tensile force capacity specified by the manufacturer which should be adhered to maintain product integrity and safety during use.
$879.85 USD
More are expected on February 17, 2025
Status: This product is temporarily out of stock.
Qty: Delivered as early as February 17, 2025 when ordered in
