STOP SHEET 650 260

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth STOP SHEET (3842545693) is a safety and protective component designed for use with conveyor units. It comprises end plates and protective covers that enhance the safety of working areas by being placed in strategic locations such as curves, diverters, junctions, and conveyor section centers. The STOP SHEET is specifically engineered to be compatible with STXH and STH end plates, with the assembly side on the right. This product's primary function is to provide protection and prevent access to moving parts of the conveyor system. The protective covers are available for various widths and roller spacings and include special designs for transitions and ends of conveyor sections. They are easily installed between rollers using spring elements that clip onto the system, ensuring a secure fit without the need for additional tools. The end plates come in different configurations: there's an end plate for the left drive side (designated as D), and one for the right drive side (E). These are critical in completing the safety barrier around moving parts. Additionally, lateral guide protective covers (F) can be ordered as needed based on system requirements. Installation hardware includes thread-forming screws (DIN EN ISO 7049 – EEMX. G), which customers must source separately, along with spring elements (H) required for securing each end plate in place. Cover caps (J) are also provided to seal open profile ends, ensuring a neat finish and added safety by covering any sharp edges or exposed ends. In summary, this STOP SHEET from Bosch Rexroth is an essential component designed to improve safety around conveyor systems by providing robust protective barriers that can be easily integrated into existing setups without extensive modifications or downtime.
