STOP SHEET 1040 260

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth STOP SHEET (Material Number 3842545688) is a meticulously designed safety component for conveyor systems. This product is an integral element that serves to enhance the safety of working environments where conveyor units are in operation. Its primary function is to act as a protective cover and end plate, which can be installed on various widths and roller spacings of conveyor units. The STOP SHEET is engineered for compatibility with curves, diverters, and junctions within the conveyor system. This STOP SHEET model includes special covers that are suitable for the center sections of conveyors, transitions, and ends, ensuring comprehensive protection across different segments of the conveying process. The product also features end plates specifically designed for both the left drive side (labeled as 'D') and the right drive side (labeled as 'E'), catering to different configurations of conveyor setups. In addition to these components, lateral guide protective covers (marked 'F') are provided and require a specific number based on application needs. To ensure secure attachment of these elements, thread forming screws (referred to as 'G') are necessary; however, customers need to source these screws separately. For each end plate ('D' or 'E'), four screws are required, while each lateral guide cover ('F') necessitates two screws. Furthermore, spring elements identified as 'H' are essential for attaching each end plate securely. These spring elements play a crucial role in maintaining the stability and reliability of the protective covers when clipped between rollers. Lastly, caps labeled as 'J' serve as cover caps for open profile ends. Each section end requires one cap to ensure complete coverage and protection. The STOP SHEET is fabricated from galvanized steel which offers durability against wear and corrosion while also supporting long-term use in industrial settings. With its robust construction and thoughtful design tailored for various applications within conveyor systems, this Bosch Rexroth product ensures enhanced safety measures are met with precision engineering standards.
